WACKER NEUSON PS2 800
WACKER NEUSON SUBMERSIBLE PUMPS — PS2 800
SUBMERSIBLE PUMPS: FLEXIBLE AND DEPENDABLE WATER REMOVAL
Designed for a variety of applications, Wacker Neuson’s large selection of submersible pumps allows you to easily remove water from construction sites, ponds and flooded areas. These single-phase, electric pumps are a cost-effective means to move water containing some solids.
SUBMERSIBLE PUMPS OF THE PS SERIES — SINGLE PHASE SUBMERSIBLE PUMP FOR COST EFFECTIVE DEWATERING
Pump can start in low water levels when it is primed through the discharge port. No matter how large or small the job. Wacker Neuson submersible pumps offer the versatility and durability contractors need for light dewatering. Suitable for most outlets, these pumps offer big pump features for small pump investment.
FEATURES
LIGHTWEIGHT, COMPACT DESIGN
• The pump is lightweight and small which makes it perfect for any application.
• Easy to store and transport.
BUILT-IN THERMAL PROTECTION PREVENTS MOTOR DAMAGE
• Built-in thermal protection prevents motor damage due to impeller blockage, reducing service repairs.
• Motor protection eliminates worry during operation.
DURABLE MECHANICAL SEALS
• Silicon carbide-faced double mechanical seals run in an isolated oil-filled cavity, allowing for seal lubrications, cooling and overall motor protection.
HEAVY-DUTY STRAIN RELIEF POWER CORD
• Robust power cord stands up to the rigors of the construction site.
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
Technical Data
| Effective power | 0.75 KW |
|---|---|
| Intake-/Pressure socket-dia. | 2.0" |
| Width for shipping | 10.5" |
| Nominal Engine speed | 3,300.0 1/min |
| Nominal frequency | 60.0 Hz |
| Cable cross-section | 0.0 Inch2 |
| Temperature limit borrowed liquid | 104.0-32.0°F |
| Cable definition | PVC Sheath |
| Height | 13.4" |
| Height for shipping | 10.2" |
| Length | 7.6" |
| Shipping weight | 36.1 lb |
| Length Cable | 49.2' |
| Flow rate max | 81.9 gal/mi |
| Solid diameter max. | 0.2" |
| Length for shipping | 18.7" |
| Delivery height max. | 59.1' |
| Nominal voltage | 110.0 V |
| Width | 7.4" |
| Operating weight | 29.1 lb |
| Nominal current | 10.1 A |
