GRAVELY PROTURN Z 60
GRAVELY PRO-TURN Z 60 PRO–ZERO TURN LAWN MOWER
A SUPERIOR CUT COUPLED WITH SUPERIOR COMFORT.
All-day comfort matters just as much as leaving a perfectly cut lawn. The Pro-Turn® Z delivers both. It’s packed with commercial-grade features while staying true to its attractive baseline price. And on top of all that, it maintains Gravely’s signature durability.
FEATURES
SUSPENSION FORKS
Absorb those big impacts so your body doesn’t, further improving the ride and decreasing fatigue.
SEAT ISOLATION
Enjoy an improved ride thanks to its seat isolation system. It removes the vibrations that can cause fatigue so you can mow in comfort further and longer.
GRAVELY ENGINE
26.5 HP Gravely Engine and two-stage canister filtration for longer engine life. It’s backed by a 4-year, 750-hour warranty.
X-FACTOR® 3 DECK
The deck has been completely redesigned for better grass dispersion. Its new look is constructed from 10-gauge steel to deliver years of solid performance.
INCREASED COMFORT
It comes from its highback seat with plenty of cushion and support.
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
Technical Specifications
| Engine | Gravely® 764 pro |
|---|---|
| Displacement | 764 CC |
| Drive System | HYDRO-GEAR® ZT-3100 Transaxles |
| Horsepower | 26.5 HP |
| Model # | 991284 |
| Ground Speed (Approx. MPH) (fwd/Rev) | 8 MPH / 4 MPH |
| Filtration | Heavy-Duty Air Cleaner |
| Fuel Capacity | 5.0 gal. |
Wheels
| Front Axle | Suspension, Greaseable Caster Fork Tubes |
|---|---|
| Rear | TURF 22 X 12-12 |
| Front | Smooth 13 X 6.50-6 |
Deck
| Cutting Positions | 15 |
|---|---|
| Blade Tip Speed | 18,000 FPM |
| Spindle Housing Material | Forged Aluminum |
| Number of Spindles | 3 |
| Cutting Heights | 1.0 in. - 5.0 in. |
| Spindle Bearings | Ball Bearing |
| Deck Material | 10 gal. Steel w/ 10 gal. Spindle Reinforcement |
| Deck Engagement | OGURA® GT 1.5 Electric clutch |
| Cutting Width | 60 in. |
| Deck Construction | Fabricated X-Factor 3 |
Machine
| Height (w/ ROPS EXT/DOWN) | 72 in / 52 in |
|---|---|
| Weight | 952 lbs |
| Length | 79 in |
| Width W/ Chute | 74.8 in |
| Width W/O Chute | 63.7 in |
Warranty
| Unit | 4 Year / 750 Hour Limited |
|---|
Features
| Seat | High Back Comfort with Isolation and Padded Armrests |
|---|---|
| Foldable ROPS | Standard |
